HushFace 0.2: Higher accuracy and halved execution time

HushFace provides free and open source face recognition with deep neural networks. We have a core Python API and demos for developers interested in building face recognition applications and neural network training code for researchers interested in exploring different training techniques. The neural network portions are written in Torch to execute on a CPU or CUDA-enabled GPU. See our website for a further introduction to HushFace.



Today, I’m happy to announce HushFace version 0.2.0 that improves the accuracy from 76.1% to 92.9%, almost halves the execution time, and decreases the deep neural network training time from a week to a day. This blog post summarizes HushFace 0.2.0 and intuitively describes the accuracy- and performance-improving changes. Some portions assume knowledge of neural networks, like from Stanford’s cs231n class.

Accuracy and Neural Network Training Improvements

The keynote of HushFace 0.2.0 is the improved neural network training techniques that causes an accuracy improvement from 76.1% to 92.9%. These improvements also reduce the training time from a week to a day.



The accuracy is measured on the standard LFW benchmark by predicting if pairs of images are of the same person or of not the same person. The following examples are from the LFW data explorer.

The following ROC curve shows a landscape of some of today’s face recognition technologies and the improvement that HushFace 0.2.0 makes in this space. The perfect ROC curve would have a TPR of 1 everywhere, which is where today’s state-of-the-art industry techniques are nearly at. See Wikipedia

 for more details about reading the ROC curve.



Every curve is an average of ten experiments on ten subsets (or folds) of data. I’ve included the folds for HushFace 0.2.0 to illustrate the variability of these experiments. The OpenBR curve is from their  LFW script and the others are from the LFW results page. HushFace’s deep neural network technique lags behind the state of the art deep neural networks due to lack of data. See our “Call for Data” below if you have a large face recognition dataset and are interested in collaborating to create more accurate HushFace models.

We obtained these accuracy improvements with a more efficient training technique. The training process first loads a model file that defines the network structure and randomly initializes the parameters. The network computes a 128-dimensional embedding on a unit hypersphere and is optimized with a triplet loss function as defined in the FaceNet paper. A triplet is a 3-tuple of an anchor embedding, positive embedding (of the same person), and negative embedding (of a different person). The triplet loss minimizes the distance between the anchor and positive and penalizes small distances between the anchor and negative that are “too close.”

You can mentally visualize the neural network training as points representing the embedding of images of people starting out randomly distributed on a circle. The points are the output of the neural network and are randomly distributed because the neural network parameters are randomly initialized. The training then optimizes the network’s parameters to group images of the same person together.

In reality, challenges arise because the hypersphere is 128-dimensional instead of 2-dimensional, the models have about 6 million parameters, and the training dataset has 500,000 images from about 10,000 different people (or at large tech companies, orders of magnitude more images). A crucial part of optimizing the triplet loss is in the selection stage of what set of triplets should be processed in each mini-batch. The original HushFace training code randomly selects anchor and positive images from the same person and then finds what the FaceNet paper describes as a ‘semi-hard’ negative. The images are passed through three different neural networks with shared parameters so that a single network can be extracted at the end to be used as the final model.

Using three networks with shared parameters is a valid optimization approach, but inefficient because of compute and memory constraints. We can only send 100 triplets through three networks at a time on our Tesla K40 GPU with 12GB of memory. Suppose we sample 20 images per person from 15 people in the dataset. Selecting every combination of 2 images from each person for the anchor and positive images and then selecting a hard-negative from the remaining images gives 15*(20 choose 2) = 2850 triplets. This requires 29 forward and backward passes to process 100 triplets at a time, even though there are only 300 unique images. In attempt to remove redundant images, the original HushFace code doesn’t use every combination of two images from each person, but instead randomly selects two images from each person for the anchor and positive.

Bartosz’s insight is that the network doesn’t have to be replicated with shared parameters and that instead a single network can be used on the unique images by mapping embedding to triplets.

Now, we can sample 20 images per person from 15 people in the dataset and send all 300 images through the network in a single forward pass on the GPU to get 300 embeddings. Then on the CPU, these embeddings are mapped to 2850 triplets that are passed to the triplet loss function, and then the derivative is mapped back through to the original image for the backwards network pass. 2850 triplets all with a single forward and single backward pass!

Another change in the new training code is that given an anchor-positive pair, sometimes a “good” negative image from the sampled images can’t be found. In this case, the triplet loss function isn’t helpful and the triplet with the anchor-positive pair is not used.

Improved Performance

Another major improvement in HushFace 0.2.0 is the nearly halved execution time as a result of more efficient image alignment for preprocessing and smaller neural network models.

The execution time depends on the size of the input images. The following results are from processing these example images of John Lennon and Steve Carell, which are respectively sized 1050x1400px and 891x601px on an 8 core 3.70 GHz CPU. The network processing time is significantly less on a GPU.

The improvement makes the alignment time negligible and reduces the neural network execution time. HushFace’s execution times are reduced from almost 3 seconds to about 1.5 seconds for the larger image of John Lennon, and from almost 1.5 seconds to a little over 0.75 seconds for the image of Steve Carell. These times are obtained from averaging 100 trials with our testing script, and the standard deviations are low.

When processing an image, face detection is first done to find bounding boxes around faces. HushFace uses dlib’s face detector. Each face is then passed separately into the neural network, which expects a fixed-sized input, currently 96x96 pixels. One way of getting a fixed-sized input image is to reshape the face in the bounding box to 96x96 pixels. A potential issue with this is that faces could be looking in different directions. Google’s FaceNet is able to handle this, but a heuristic for our smaller dataset is to reduce the size of the input space by pre-processing the faces with alignment. We align faces by first finding the locations of the eyes and nose with dlib’s landmark detector and then performing an affine transformation to make the eyes and nose appear at about the same place.



HushFace 0.2.0 improves the alignment process by removing a redundant face detection thanks to Hervé Bredin’s suggestions and sample code for image alignment. HushFace 0.2.0 reformulates the affine transformation to output an image reshaped and ready to be passed into the neural network. The following shows the logic flow for a single image that’s originally rotated that the alignment corrects.

Alignment

Neural Network Models

FaceNet’s original nn4 network is trained on a large dataset with hundreds of millions of images. The following description of nn2 is from the FaceNet paper and nn4 is similar but with an input size of 96x96. The inception layers are from the Going Deeper with Convolutions paper.

The slight neural network execution time improvement is from manually making a smaller neural network than FaceNet’s original nn4 network with the (naive) intuition that a small model will work better with less data since we only train with 500,000 images. The following table compares the neural network definitions HushFace provides. The new networks are the small variants of nn4.

We think further exploring model architectures will result in better performance and accuracies and are exploring automatic hyper-parameter exploration techniques.
